AMPLIFIER:# Channels 9.2
POWER (8 Ω 20-20kHz 0.08%) / CH 120
Amplifier Frequency Response 5Hz - 100kHz
Wide Range, High Current Power Supply Natural Harmonics Technology, Massive High-Power Transformer
High Instanteneous Current Capability 35 Amps, 1kHz, 0.1 Ω, 1 Pulse
THX Certified ✓ www.av269.com
Continuous 6 Ω Rated ✓
Low Impedance Drive- Certified 4 Ω ✓
Hand Selected Parts to Ensure Low Impedance Performance Custom- Audio Tuned
Discrete Output Stages for All Channels Discrete 2-Stage
All Channels Equal Power Output ✓
PUSH-PULL Amplifier Design ✓
Separate Digital and Analog Circuitry to Reduce Interference
Independent Power Supply 2
Bi-amp Capability - Front L/R Channels ✓
PROCESSING:
Dolby Atmos and Dolby Surround ✓
Dolby TrueHD ✓
DTS:X and DTS Neural:X ✓
DTS-HD Master Audio ✓
THX Processing Modes & Loudness Plus ✓
VLSC for Noise Free Signal Path ✓ (Front Channels)
AccuEQ Automatic Room Calibration Advance w/AccuReflex
GAME Surround Modes (Rock, Action, Sports, Role Play) ✓
Advanced Music Optimizer to Enhance Compressed Audio Files ✓
Standing Wave EQ ✓
Premium Quality Digital-to-Analog Conversion 384k / 32-bit AKM4458 Differential DAC
32-Bit DSP Chip for Advanced Processing ✓
Ultra-Low-Jitter Circuitry to Improve Audio ✓
Adjustable Crossover by Channel Pair 40/45/50/55/60/70/80/90
100/110/120/130/150/180/200 Hz
Accurate Speaker Distance Setting 0.1 - foot
A/V Sync Delay (by Source) -100 to +500 ms
CONNECTIVITY:
HDMI Inputs / Output(s) 7 / 2
4K / 60 Hz 4:4:4 Colorspace Support ✓ (Front HDMI does not fully support)
HDCP 2.2 Copy-Protection Compatibility ✓
Dolby Vision, HDR10 Support ✓
HLG (Hybrid Log Gamma), HDR10, WCG (Wide Color Gamut) Support ✓
HDMI Support for BT.2020 ✓
HDMI Support for 3D, Audio Return Channel and CEC ✓
Enhanced Audio Return Channel (eARC)
HDMI Support for Deep Color, x.v.Color, LipSync ✓
HDMI Support for DVD-Audio, SACD, Multichannel PCM ✓
Front Panel HDMI Input ✓
HDBaseT Output ✓
HDBaseT 4K / 60p / 4:4:4 Support ✓
HDBaseT Dolby Vision, HLG, WCG, POC Support ✓
HDBaseT IR / RS-232 Pass-through ✓
Analog to HDMI Upconversion From 480i to 480p
4K Upscaling from 1080p
Component Video Inputs 2
Composite Video Inputs 2
Digital Audio Inputs (COAX / OPT) 1 / 2
Analog Audio Inputs 8
Phono Input ✓
Front Panel A/V Input
Analog Pre-outs 11.2
Subwoofer Outputs 2
NETWORK / USB:
Works with Sonos ✓ (requires FW update & Sonos Connect)
Google Chromecast built-in ✓
Google Assistant (Voice Control) ✓
FlareConnect Wireless Multi-Room Audio Streaming Technology ✓
DTS Play-Fi ✓
DTS Play-Fi App for iOS and Android Integra Music Control
App Control via iOS and Android-Powered Devices Integra Control Pro
Apple Airplay ✓
iPod / iPhone / iPad Ready
Home Network Music Streaming ✓
TIDAL High Fidelity Music Streaming ✓
Amazon Music ✓ (accessible via Integra Music Control app)
Pandora ✓
Spotify ✓
Spotify Connect ✓
TuneIn Radio ✓
Deezer ✓
DSD Support 2.8, 5.6, 11.2 MHz
Dolby TrueHD Support ✓
Apple Lossless (ALAC) Support ✓
WAV Support ✓
AIFF Support ✓
DSDIFF Support ✓
FLAC Support ✓
MP3 Support ✓
USB Input for Streaming Audio ✓
WiFi Certified
Bluetooth
Firmware Updates via Network and USB ✓
MULTIZONE:
Powered Zone 2 ✓
Powered Zone 2 A / B
Powered Zone 3 ✓
Fixed or Variable Zone 2 Line Out ✓
Fixed or Variable Zone 3 Line Out ✓
Zone 2 Video Output HDMI
Zone 2 OSD ✓
Zone 2 Audio DAC HDMI (2Ch PCM), Coax, Optical, NET, USB
Zone 3 Audio DAC NET, USB, Whole House Mode
Whole House Mode HDMI (2Ch PCM), Coax, Optical, NET, USB, Analog
Remote Play Zone- Selectable
INTEGRATION ACCESS:
Bi-directional RS-232 Control Port ✓
Bi-directional Ethernet Control Port ✓
Rear Panel IR Input / Output 2 / 1
RIHD (Remote Interactive over HDMI) ✓
12V Trigger (with Adjustable delay) x3, Assignable
MISCELLANEOUS:
Research Grade Construction
GUI for Setup Menu ✓ (Advanced HD)
Quick Setup Menu ✓
Input Name Edit Fully Customizable
HDMI Standby "Through" Mode Assignable
Dealer Settings Memory Store & Recall Function ✓
Screensaver Function ✓ (Advanced)
Hybrid Standby to Reduce Power Consumption ✓
Smart Grid Ready ✓
Anti-Resonant Aluminum Front Panel ✓
Gold-Plated RCA Terminals ✓
Oversized Detachable AC Cord ✓
Rack Mount Kit Available IRK-180-4C
AMPLIFIER SECTION:
Power Output (8 Ω, 20 Hz-20 kHz, FTC) 120W / Channel (8 Ω)
Dynamic Power 250W / Channel (3 Ω)
220W / Channel (4 Ω)
130W / Channel (8 Ω)
THD (Total Harmonic Distortion + Noise) 0.08% (20 Hz-20 kHz, Half Power)
Input Sensitivity and Impedance 200 mV / 47 k-Ω (LINE)
3.5 mV / 47 k-Ω (Phono MM)
Rated RCA Output Level and Impedance 1 Vrms / 470 Ω (Subwoofer Pre Out)
1 V/200 mV / 470 Ω (Zone Pre/Line Out)
Phono Overload 70 mV (MM 1 kHz, 0.5%)
Frequency Response 5 Hz - 100 kHz / +1 dB-3 dB (Direct Mode)
Tone Control ±10dB, 20 Hz (Bass)
±10dB, 20 kHz (Treble)
Signal-to-Noise Ratio 106 dB (Line, IHF-A)
80 dB (Phono)
Speaker Impedance 4 Ω - 16 Ω
VIDEO SECTION:
Input Sensitivity / Output Level and Impedance 1.0 Vp-p / 75 Ω (Component Y)
0.7 Vp-p / 75 Ω (Component Pb/Pr)
1.0 Vp-p / 75 Ω (Composite)
TUNER SECTION:
Tuning Frequency Range FM 87.5 MHz - 107.9 MHz
AM 530 kHz - 1,710 kHz
FM / AM Preset Memory 40 Stations
GENERAL:
Power Supply AC 120 V, 60 Hz
Power Consumption 850 W
Stand-by Power Consumption 0.15 W
Dimensions (W X H X D) 17 1/8" x 7 13/16" x 15 15/16"
435 x 198 x 388.5 mm
Weight 30.9 lbs. (14.0 kg)
CARTON:
Dimensions (W X H X D) 22 15/16" x 12 11/16" x 18 3/8"
582 x 317 x 521 mm
Weight 37.5 lbs. (17.0 kg)
