quadral IWS定制安装音箱系统虽然采用隐藏安装，但音质毫不逊色，不管是聆听音乐或是观赏电影，您所安装的音响系统都可以实现无瑕精准的声音重放——清澈细腻、逼真震撼，绝不逊色于一套优秀的传统扬声器。这正是我们 IWS系列产品的优势所在。
The quadral IWS Custom Installation Speaker System uses invisible(hidden) installation, however the sound quality is very outstanding. No matter for music listen or watch movie, the speaker system you installed can both realize accurate sound reproduction—Clear & Detail, Real & Shocking, they are not less than any of the traditional good speakers. This is the advantage of our custom installation lineups.
quadral IWS入墙式产品不仅能提供震撼的环绕声性能，而且可以隐蔽安装，与现代室内装修设计形成整体风格融合，音箱将成为你的整体家装的一部分。
The quadral IWS inwall products can not only provide shocking surrounding performance, but also be invisible installation, they will blend with the modern room decoration style, and the speakers will be a part of your home decoration.
quadral IWS641系列音箱采用3音路密封式箱体设计，厚实坚固铝合金前障板，达到消除谐振的效果。高音采用波导面板实现可控色散，提供优化的离轴和功率响应；5寸中音单体采用大型90 mm磁铁结构，确保高效率和最佳T / S参数。大型32毫米音圈确保高功率处理 ，新型优化的编织玻璃纤维锥确保了大带宽和低失真，通过有效的排气和添加内部铝短路环来稳定气隙中的磁场，进一步减少了失真；6.5寸低音单体采用大直径音圈，可实现更好的控制和功率处理，内置铝合金场稳定环，可在高功率水平下减少失真，具有出色的深沉低音性能和动态。
The quadral IWS641 series speaker system uses sealed chamber 3 way system design, the thick solid aluminum front panel achieves the vibration noise cancellation effect. The tweeter uses waveguide plate achieves controllable dispersion, providing optimized off-axis and power response;
The 5”driver uses 90mm motor structure to ensure the high efficiency and best T/S data. The 32mm voice coil ensure high power, the latest optimizing woven glass fiber phase plug ensure the large andwidth & low THD, The magnetic field in the air gap can be stabilized by effective exhaust and adding internal aluminum short circuit ring, which can reduce distortion at high power level, and has excellent midrange, deep bass and dynamic performance.
The 6.5”driver uses big Outer Dimension Voice Coil for better control and power handling, The magnetic field in the air gap can be stabilized by effective exhaust and adding internal aluminum short circuit ring, which can reduce distortion at high power level, and has excellent midrange, deep bass and dynamic performance.
颜色：白色
阻抗：4欧姆
灵敏度：:92db（2.83V/1M）
频率响应：65-30KHz
分频点：240Hz/2.3kHz
驱动单元：LF:6.5INCH*2/MID5INCH/HF:1INCH
推荐功率：100-240W
总尺寸：H*W*D674mm x324mm x105mm
安装深度：100mm
切割尺寸：H*W644mm x 294mm
SELECT COLOUR:White
NOMINAL IMPEDANCE: 4 Ω
SENSITIVITY:92db（2.83V/1M）
FREQUENCY RESPONSE:65-30KHz
CROSSOEER FREQENCIES:240Hz/2.3kHz
DRIVE UNITS:LF:6.5INCH*2/MID5INCH/HF:1INCH
RECOMMENDED AMPLIFIER POWER:100-240W
PRODUCT EXTERNAL DIMENSIONS:H*W*D674mm x324mm x105mm
MOUNTING DEPTN FROM SURFACE:100mm
CUT OUT DIMENSIONS:H*W644mm x 294mm
